5.0mm TP-1/2 High Frequency Printed Circuit Board Alternative High DK RF PCB
(Printed Circuit Boards are custom-made products, the picture and parameters shown are just for reference)
General Description
This is a type of microwave PCB which is built on Wangling’s TP-1/2 substrate (DK 10.0). It is a double layer build up on 5.0mm laminate. Surface finish is hot air soldering level (HASL) with black solder mask. Both layers are 1 oz copper finished. The boards are fabricated per IPC 6012 Class 2 using supplied Gerber data. Every 20 boards are packed for shipment.
PCB Specifications
| PCB SIZE | 50 x 61mm=1up |
| BOARD TYPE | Double sided PCB |
| Number of Layers | 2 layers |
| Surface Mount Components | YES |
| Through Hole Components | NO |
| LAYER STACKUP | copper ------- 17um(0.5 oz)+plate TOP layer |
| TP-1/2 5.0mm | |
| copper ------- 17um(0.5 oz) + plate BOT Layer | |
| TECHNOLOGY | |
| Minimum Trace and Space: | 197 mil / 118 mil |
| Minimum / Maximum Holes: | 2.0 mm / 6.0 mm |
| Number of Different Holes: | 2 |
| Number of Drill Holes: | 8 |
| Number of Milled Slots: | 0 |
| Number of Internal Cutouts: | 0 |
| Impedance Control: | no |
| Number of Gold finger: | 0 |
| BOARD MATERIAL | |
| Glass Epoxy: | TP-1/2 5.0mm, DK 10.0 |
| Final foil external: | 1.0 oz |
| Final foil internal: | N/A |
| Final height of PCB: | 5.1 mm ±0.12 |
| PLATING AND COATING | |
| Surface Finish | HASL Lead free |
| Solder Mask Apply To: | Top layer |
| Solder Mask Color: | Black |
| Solder Mask Type: | LPI |
| CONTOUR/CUTTING | Routing |
| MARKING | |
| Side of Component Legend | N/A |
| Colour of Component Legend | N/A |
| Manufacturer Name or Logo: | N/A |
| VIA | Plated through hole(PTH), minimum size 2.0mm. |
| FLAMIBILITY RATING | 94V-0 |
| DIMENSION TOLERANCE | |
| Outline dimension: | 0.0059" |
| Board plating: | 0.0029" |
| Drill tolerance: | 0.002" |
| TEST | 100% Electrical Test prior shipment |
| TYPE OF ARTWORK TO BE SUPPLIED | email file, Gerber RS-274-X, PCBDOC etc |
| SERVICE AREA | Worldwide, Globally. |
The typical applications for this material include aircraft collision avoidance systems, GPS antennas, microstrip patch antenna, passive components and satellite components.
Typical Value of TP-1/2
| Name | Test condition | Unit | Value |
| Density | Normal state | g/cm3 | 1.0~2.9 |
| Moisture Absorption | Dip in distilled water of 20±2℃ for 24 hours | % | ≤0.02 |
| Peel strength | In normal state | N/cm | ≥6 |
| In the environment of alternating humidity and temperature: | N/cm | ≥4 | |
| Operating Temperature | High-low temperature cabinet | ℃ | -100～+150(Processing temperature should not exceed 200℃) |
| Thermal Conductivity | -55~288℃ | W /m /k | 0.6 |
| CTE | Temperature rise of 96℃ per hour | < 6×10-5 | |
| Shrinkage Factor | 2 hours in boiling water | % | 0.0004 |
| Surface Resistivity | 500V DC Normal state | M.Ω | ≥1×107 |
| 500V DC Constant humidity and temperature | M.Ω | ≥1×105 | |
| Volume Resistivity | Normal state | MΩ.cm | ≥1×109 |
| Constant humidity and temperature | ≥1×106 | ||
| Surface dielectric strength | Normal state | Kv/mm | ≥1.5 |
| Constant humidity and temperature | ≥1.2 | ||
| Dielectric Constant | 10GHz | εr | 3, 6, 9.6, 10.2, 10.5, 11, 16, 20, 22(±2%)(DK can be customized) |
| Dissipation Factor | 10GHz | Tgδ(εr 3-11) | ≤1×10-3 |
| Tgδ(εr 12-22) | ≤1.5×10-3 |
Other Available High Frequency Materials
Rogers RO4350B, RO4003C, RO4730G3, RO4360G2, RO4533, RO4534, RO4535, RO3003, RO3035, RO3006, RO3010, RO3210, RO3203, etc.
Rogers RT/duroid 5880, RT/duroid 5870, RT/duroid 6002, RT/duroid 6010, RT/duroid 6035HTC etc.
Rogers TMM4, TMM10, Kappa 438 etc.
PTFE F4B DK2.2, DK2.65
Taconic TLX-0, TLX-9, TLX-8, TLX-7, TLX-6, TLY-5, TLY-3, RF-35TC, RF-35, TLF-35, RF-60A, RF-60TC, RF-35, RF-35A2, RF-45, TRF-45, RF-10 etc.
AD450, AD600, AD1000, TC350 etc.
|
|
