In the rapidly advancing field of electronics, the demand for high-performance printed circuit boards (PCBs) is critical for driving innovation and ensuring reliability. Our 4-layer PCB, constructed using Rogers RO3210 material, is meticulously engineered to meet the stringent requirements of modern applications, particularly in high-frequency environments.

Material Overview: Rogers RO3210

At the heart of this PCB is Rogers RO3210 substrate, a high-frequency circuit material that integrates ceramic-filled laminates with woven fiberglass reinforcement. This unique combination delivers not only exceptional electrical performance but also superior mechanical stability, making it a prime choice for cutting-edge electronic designs.

PCB Specifications

Key Features of Rogers RO3210:

- Dielectric Constant (Dk): 10.2 ± 0.5, ensuring minimal signal loss and optimal performance characteristics at high frequencies.

- Dissipation Factor: A low value of 0.0027 at 10 GHz enhances energy efficiency during signal transmission.

- Coefficient of Thermal Expansion (CTE): Matched to copper, with values of 13 ppm/°C for the X and Y axes and 34 ppm/°C for the Z axis, providing excellent dimensional stability.

- Thermal Decomposition Temperature (Td): Exceeds 500°C, ensuring reliable operation under rigorous thermal conditions.

- Thermal Conductivity: At 0.81 W/mK, this material facilitates effective heat dissipation, critical for high-frequency applications.

- Flammability Rating: Rated V0 according to UL 94 standards, ensuring safety in a range of applications.

Quality Assurance

Every PCB undergoes rigorous quality assurance, with a 100% electrical test performed before shipment. This ensures that each board meets the highest standards of reliability and performance, complying with IPC-Class-2 standards.

Versatile Applications

The versatility of this PCB makes it ideal for various high-frequency applications, including:

- Automotive Collision Avoidance Systems: Enhancing vehicle safety through sophisticated sensing technologies.

- GPS Antennas for Automotive: Providing accurate location tracking for navigation systems.

- Wireless Telecommunications Systems: Supporting robust communication networks for mobile devices.

- Microstrip Patch Antennas: Facilitating effective wireless communications in various settings.

- Direct Broadcast Satellites: Delivering high-quality signals for satellite communications.

- Datalink on Cable Systems: Ensuring efficient and reliable data transmission.

- Remote Meter Readers: Improving utility management with real-time data collection.

- Power Backplanes: Supporting high-performance power distribution in complex electronic systems.

- LMDS and Wireless Broadband: Enabling high-speed internet access for consumers and businesses alike.

- Base Station Infrastructure: Providing essential support for cellular communication networks.

Conclusion

This 4-layer PCB featuring Rogers RO3210 material stands as a testament to the forefront of PCB technology, delivering exceptional performance, reliability, and versatility. Its innovative design and high-quality specifications make it an ideal solution for a wide array of modern applications.

Investing in this advanced PCB solution ensures that your products not only meet the challenges of today's technological landscape but also excel in performance and efficiency. Whether your focus is on telecommunications, automotive systems, or consumer electronics, this PCB is designed to provide the high performance your applications demand.

For further inquiries or to place an order, please reach out to us today—let’s collaborate to elevate your electronic solutions to new heights!
